Common materials: 304, 316L stainless steel
Surface treatment: mirror polishing, pickling, passivation
Nominal pressure: suitable for standard pressures such as PN10 and PN16
Standard specifications: in line with sanitary pipe standards DIN 11851, SMS 3008, ISO 2852, etc.
Certification: in line with 3A certification, FDA certification and other industry hygiene requirements
Nominal diameter: 1/2" to 6" (customizable upon request)
Common specifications: DN15, DN20, DN25, DN50, DN100
Wall thickness: common wall thickness is 1.5mm, 2mm, 2.5mm (customizable upon request)
Applicable pipeline standards: SMS, DIN, ISO, pipelines of different standards can match different specifications of joints
Connection method
Quick-install connection: Joints are generally connected by clamps, threads, etc., which is convenient for quick installation and removal
Clamp connection: The sealing device composed of clamps and joints can be quickly disassembled and maintained while maintaining sealing, which is suitable for pipeline systems that are frequently disassembled and cleaned
Threaded connection: Suitable for small-diameter pipeline systems to ensure a stable connection and prevent leakage
Ra value requirement: Ra ≤ 0.8μm
Conventional temperature range: -196°C to +600°C, suitable for most conventional piping systems
Conventional pressure: suitable for common pressure levels such as PN10, PN16
Application areas
Food industry: used for food liquid delivery pipelines
Beverage industry: used for beverage production lines
Pharmaceutical industry: used for the production and delivery of medicines
Chemical industry: used for the delivery of non-corrosive or slightly corrosive chemicals
Common models
Sanitary quick-release joints: suitable for piping systems that require frequent disassembly and cleaning in industries such as food and medicine
Sanitary welding joints: suitable for piping systems that require long-term fixed installation
Sanitary three-way joints: used for connecting pipe branches,
Sanitary reducing joints: used for connecting pipes of different diameters
Installation and maintenance
Easy installation: The quick-release design of the joint makes installation very easy, especially suitable for occasions with frequent disassembly and maintenance
Regular inspection: After installation, it is necessary to regularly check the tightness and sealing of the joint to prevent loosening or leakage during long-term use
Cleaning and maintenance: Clean the pipeline system regularly to ensure the hygiene of the pipeline system and avoid accumulation of dirt or bacteria
